3M 2PCID Fire Barrier Cast-In Device for Plastic Pipes – 2″

This 3M Fire Barrier Cast-In Device for Plastic Pipes 2PCID is an intumescent device that firestops 2 inch (50.8 mm) non-metallic penetrations through fire-rated concrete floor assemblies. It is installed by attaching directly to the form before a concrete slab is poured.
Details:

• Firestop tested for up to 3 hours in accordance with ASTM E 814 (UL 1479)
• Models for metallic (black cap) and non-metallic (white cap) penetrating items
• Easily adjusted height accommodates concrete thickness from 2-1/two inches up to 8″ (57.2 mm to 203.2 mm)
• Meets UL Water Leakage Test, W Rating — Class 1 requirements for systems tested and listed in accordance with ANSI/UL 1479 (see system details)
• UL Classified for 2 and 3 hours of fire (F) rating, 1 and 3 hours of temperature (T) rating
• Installs securely by attaching directly to flooring deck
• Rugged one-piece design to withstand every-day bumps, kicks and hard knocks of the construction process
• Red colour easily identifiable as fire-rated device

Suggested Applications:

• May be applied to two inches non-metallic pipe and HVAC line sets in drain, waste, supply and vented or closed pipe systems
• Commonly used to firestop ccPVC, PVC, RNC and CPVC pipes penetrating concrete floors with fire-ratings up to 3 hours
• Use the appropriately-sized device as listed in system details (black-capped devices for metallic penetrations and white-capped devices for non-metallic penetrations)
