3M™ Fire Barrier Rated Foam, FIP 1-Step, 12.85 fl. oz. (380 mL) cartridge



2 Nozzels Included per Cartridge.

3M Fire Barrier Rated Foam FIP 1-Step is a firestop foam used to fill the annular space created by pipes and cables penetrating through fire-rated construction. This product foams in place filling the void between the through penetrant (pipe, cable etc.) and the wall creating a firestop seal restoring the fire rating of the entire wall.

Features:

• Firestop tested up to two hours in accordance with ASTM E 814 (UL 1479) and CAN/ULC S115
• Meets the International Building Code for Passive Fire Protection
• Expands up to 5X when dispensed. One cartridge FIP 1-Step equals up to 6 tubes 10.1 oz. caulk
• Intumescent. Expands in a fire
• Expansive UL systems for blank openings, metal pipe, cables, cable trays, combos, insulated pipe
• UL systems require no mineral wool
• Remains pliable after installation for easy installation of new cables/conduit in existing opening
• Can be installed in wall or floor applications with no backing material
• Quick cure with full expansion after approximately 2 minutes
• Paintable with primer
• STC rating of 57 when tested in STC 57 rated wall assembly
• Air leakage less than 1 CFM/sq. ft. (1.7 m/hr)
• Meets the intent of LEED VOC regulations. <250 g/L VOC contents (less H2O and exempt solvents)

Specifications:

• Applications – Electrical, Electrical Maintenance
• Brand – 3M
• Fire Rating – 2 Hour
• Product Type – Foam
• Size – 12.85 Fluid Ounce (US)
• Smoke Seal – Yes
• Sound Barrier – 57 in 57
• Volume – 12.85 Fluid Ounce
• Volume (metric) – 380 ml
